Catalogue / Switchgear / Havells X7 MCB DP — 32 A
BrandHavells
CategorySwitchgear
SpecificationCircuit Breaker · Execution pole Double Pole (DP) · Type C Curve · Rating 63 A
SKUDHMYCDPM032
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 3–7 working days
Havells· In stock
Havells X7 MCB DP — 32 A
Rating: 32 A
₹504/pc+ 18% GST
₹595 incl. GST · MRP ₹85641% off
Wholesale · 15+ units
₹479 +GST /pc
Add to cart
Buy now
🚚 Delivered pan-India · 30-day NBFC credit is coming soon — join the waitlist.
Price history
Elume price over time. Market comparison appears once we track this item. Updated regularly.
ElumeMRP
Elume today
₹595
MRP
₹1,010
1 price point
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
3–7 working days to any site in India
📦
Wholesale built in
−5% auto-applies at 15+ units — ₹565/pc on this product
About this product
from havells.com63 A
- Application : For industrial and commercial purposes
- Rating : 6 A to 63 A
- Specification : IS/IEC 60898-1 & IEC 60898-1
- Note: Product images are for illustrative purposes and may differ from the actual product
Air Circulation
When two poles are placed adjacent to each other, the channels between two poles form a tunnel resulting in very effective air circulation around individual poles.
DIN Rail Mountable
DIN Rail Mountable for easy mounting/ demounting inside DB.
Dual Connect Terminal
Dual connect terminal at incoming side - Two types of busbars can be used, that is, Fork Type and Pin Type.
Terminal
The terminals are suitable for cables up to 25 mm 2 cross section area thus making it suitable for copper and aluminum cables.
Knob Locking
OFF position for personal safety during maintenance, ON position for extremely critical load
Trip Free Mechanism
Trip free mechanism – MCB trips even if held in ON position.
Life Saver, Energy Saver
Low efficient watt loss, thus energy.
As published by Havells. Verify critical parameters against the datasheet before specifying.
Technical specifications
Havells Havells X7 MCB DP — 32 A · DHMYCDPM032
Device typeMiniature circuit breaker (MCB)
Current rating32 A
Poles2-pole (DP)
Reference standardIS/IEC 60898-1
BrandHavells
SKUDHMYCDPM032
Sold asPer pc
TypeC Curve
Rating63 A
Net Quantity1 N
Product rangeCircuit Breaker
Execution poleDouble Pole (DP)
Manufactured ByHavells India Ltd.
Country Of OriginIndia
The full range · 8 options
Every option is its own product with live pricing — tap a row to switch.
| Option | Rating | Elume price (ex-GST) | MRP | Off |
|---|---|---|---|---|
| Havells X7 MCB DP — 6 AParent | 6 A | ₹504 | ₹856 | 41% |
| Havells X7 MCB DP — 10 A | 10 A | ₹504 | ₹856 | 41% |
| Havells X7 MCB DP — 16 A | 16 A | ₹504 | ₹856 | 41% |
| Havells X7 MCB DP — 20 A | 20 A | ₹504 | ₹856 | 41% |
| Havells X7 MCB DP — 25 A | 25 A | ₹504 | ₹856 | 41% |
| Havells X7 MCB DP — 32 AViewing | 32 A | ₹504 | ₹856 | 41% |
| Havells X7 MCB DP — 40 A | 40 A | ₹746 | ₹1,268 | 41% |
| Havells X7 MCB DP — 63 A | 63 A | ₹806 | ₹1,369 | 41% |
Know before you buy
Read: Top 10 MCBs & Switchgear in India (2026) →What is the difference between an MCB, an RCCB and an RCBO?
An MCB protects against overload and short circuit (overcurrent). An RCCB protects against earth leakage and electric shock by detecting current imbalance, typically at 30mA, but offers no overcurrent protection. An RCBO combines both functions in one module, giving overcurrent and earth-leakage protection per circuit, saving DIN-rail space.
Should I use a Type AC or Type A RCCB in India?
Type AC detects only AC earth leakage and suits basic resistive and inductive loads. Type A also detects pulsating DC leakage produced by electronics, EV chargers, inverters and LED drivers. Since most Indian homes now run such loads, Type A is the safer choice. Use Type B for solar inverters and variable-frequency drives.
What breaking capacity (kA) do I need for an Indian home?
Breaking capacity is the maximum fault current an MCB can safely interrupt. For most homes located some distance from the transformer, 6kA is adequate. For apartments, boards close to the distribution transformer, and commercial mains, specify 10kA or higher. Always base it on the actual prospective short-circuit current at your board.
