Schneider Zelio Logic Discrete I/O Extension Module · 14 I O · 100..240 V AC · for Zelio LogicSR3XT141FU↓ 1% off MRP1 / 6
BrandSchneider
CategoryIndustrial Control
Brand SKUSR3XT141FU
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 3–7 working days
Schneider· In stock
Visit the Schneider store

Schneider Zelio Logic Discrete I/O Extension Module · 14 I O · 100..240 V AC · for Zelio Logic

NEW added this week
₹18,295/pcincl. GST-1%
₹15,504 + 18% GST · MRP ₹18,480
Add to cart
Buy now
  • Secured by Razorpay · UPI, cards, net banking, wallets
  • GST invoice with every order
  • Tracked delivery, 3 to 7 working days
✓ Full brand warranty on every order
✓Lowest price guarantee · found it cheaper? We match it.
💳 30 Day credit facility available launching soon - join waitlist.
₹18,295 /pc incl. GST
Free pan-India delivery

Schneider Zelio Logic Discrete I/O Extension Module · 14 I O · 100..240 V AC · for Zelio Logic: Elume price today ₹18,295 per pc incl. GST, 1% below the ₹18,480 MRP. The price has held steady for the last 30 days.

Price history
Elume price over time, day by day. Market comparison appears once we track this item.
13 Oct to 19 Oct
₹19,774₹19,084₹18,394₹17,704₹17,014₹18,480₹18,295
13 Oct14 Oct15 Oct16 Oct17 Oct18 Oct19 Oct
Elume today
₹18,295
MRP
₹18,480
Lowest in view · 17 Oct
₹18,295
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
3–7 working days to any site in India
📦
Wholesale built in
−5% auto-applies at 15+ units - ₹17,380/pc on this product

This Zelio Logic SR3 discrete I/O extension module smart relays uses a supply voltage of 100V-240V alternating current. It has 14 inputs / outputs contact with screw-clamp terminals. It enables simple ladder programming, adapted for non-specialists.

As published by Schneider. Verify critical parameters against the datasheet before specifying.
Schneider Schneider Zelio Logic Discrete I/O Extension Module · 14 I O · 100..240 V AC · for Zelio Logic · SR3XT141FU
Ingress protectionIP20 (terminal block)· IP40 (front panel)
Reference standardIEC 61000-4-6 level 3
Net weight0.22 kg
BrandSchneider
Brand SKUSR3XT141FU
ELINEDH7P9R2FH
Sold asPer pc
ChecksProgram memory on each power up
StandardsIEC 61000-4-6 level 3 · IEC 61000-4-2 level 3 · IEC 61000-4-4 level 3 · IEC 60068-2-27 Ea · IEC 61000-4-5 · IEC 61000-4-11 · IEC 60068-2-6 Fc · IEC 61000-4-12 · IEC 61000-4-3
Cycle time6…90 ms
Backup time10 years at 25 °C
Clock drift12 min/year at 0…55 °C
Response time50 ms with ladder programming (from state 0 to state 1) for discrete input · 50 ms with ladder programming (from state 1 to state 0) for discrete input · 50...255 ms with FBD programming (from state 0 to state 1) for discrete input · 50...255 ms with FBD programming (from state 1 to state 0) for discrete input · 10 ms (from state 0 to state 1) for relay output · 5 ms (from state 1 to state 0) for
Input impedance350 kOhm for discrete input
Pollution degree2 conforming to IEC 61131-2
Range of productZelio Logic
Supply frequency50/60 Hz
Number of outputs6 relay
Relative humidity95 % without condensation or dripping water
Tightening torque0.5 N.m
Operating altitude2000 m
Operating rate in Hz0.1 Hz (at Ie) for relay output · 10 Hz (no load) for relay output
Overvoltage categoryIII conforming to IEC 60664-1
Discrete input number8
Electrical durabilityAC-15: 500000 cycles at 230 V, 0.9 A for relay output conforming to IEC 60947-5-1 · AC-12: 500000 cycles at 230 V, 1.5 A for relay output conforming to IEC 60947-5-1 · DC-13: 500000 cycles at 24 V, 0.6 A for relay output conforming to IEC 60947-5-1 · DC-12: 500000 cycles at 24 V, 1.5 A for relay output conforming to IEC 60947-5-1
Mechanical durability10000000 cycles for relay output
Output voltage limits5...30 V DC (relay output) · 24...250 V AC
Supply voltage limits85…264 V
Discrete input current0.6 mA
Discrete input voltage100...240 V AC
Output thermal current5 A for 2 outputs for relay output · 8 A for 4 outputs for relay output
Product certificationsC-Tick · GOST · CSA · GL · UL
Connections - terminalsScrew terminals, 1 x 0.25...1 x 2.5 mm² (24 AWG...14 AWG) flexible with cable end · Screw terminals, 2 x 0.25...2 x 0.75 mm² (24 AWG...18 AWG) flexible with cable end · Screw terminals, 1 x 0.2...1 x 2.5 mm² (25 AWG...14 AWG) semi-solid · Screw terminals, 1 x 0.2...1 x 2.5 mm² (25 AWG...14 AWG) solid · Screw terminals, 2 x 0.2...2 x 1.5 mm² (24 AWG...16 AWG) solid
IP degree of protectionIP20 (terminal block) conforming to IEC 60529 · IP40 (front panel) conforming to IEC 60529
Discrete input frequency57...63 Hz · 47...53 Hz
Switching capacity in mA>= 10 mA at 12 V (relay output)
Product or component typeDiscrete I/O extension module
[Us] rated supply voltage100...240 V AC
Current state 0 guaranteed<= 0.5 mA (discrete input)
Current state 1 guaranteed>= 0.17 mA (discrete input)
Maximum altitude transport3048 m
Voltage state 0 guaranteed<= 40 V for discrete input
Voltage state 1 guaranteed>= 79 V for discrete input
Reverse polarity protectionWith
Environmental characteristicEMC directive conforming to IEC 61000-6-2 · EMC directive conforming to IEC 61000-6-3 · EMC directive conforming to IEC 61000-6-4 · EMC directive conforming to IEC 61131-2 zone B · Low voltage directive conforming to IEC 61131-2
Contacts type and compositionNO for relay output
Disturbance radiated/conductedClass B conforming to EN 55022-11 group 1
Number or control scheme lines120 with ladder programming
Ambient air temperature for storage-40…70 °C
Ambient air temperature for operation-20…40 °C in non-ventilated enclosure conforming to IEC 60068-2-1 and IEC 60068-2-2 · -20…55 °C conforming to IEC 60068-2-1 and IEC 60068-2-2
[Uimp] rated impulse withstand voltage4 kV conforming to EN/IEC 60947-1 and EN/IEC 60664-1
Ratings as published by Schneider (se.com). Verify critical parameters against the datasheet before specifying.
Is Schneider Zelio Logic Discrete I/O Extension Module · 14 I O · 100..240 V AC · for Zelio Logic genuine and warranty-backed?

Yes. Every Schneider product on Elume is 100% genuine, sourced through authorised channels, and carries the manufacturer's standard warranty.

Do you deliver across India?

Yes. We deliver anywhere in India our couriers serve, usually within 3 to 7 working days from order confirmation. The delivery charge follows the order value (the GST-inclusive goods total after any discount code): ₹200 under ₹2,000; ₹100 from ₹2,000 to under ₹4,000; free from ₹4,000 to ₹25,000; ₹1,000 above ₹25,000, because large orders ship insured, often in several boxes. Heavy consignments add ₹1,000 for every started 10 kg beyond the first 10 kg of the order's total shipping weight, even when delivery is free. A free-delivery code makes the whole delivery charge zero. Every charge is shown at checkout before you pay.

Can I get a GST invoice?

Yes, on orders delivered in India. Enter your GSTIN at checkout and we issue a GST invoice with tax shown separately, so businesses can claim input tax credit.

Is there a wholesale or bulk rate?

Yes. Orders of 15 or more pcs get a wholesale rate about 5% below the listed Elume price, shown on every product page.

What if I find it cheaper somewhere else?

Tell us. If the same Schneider product is listed for less, GST and delivery included, by an authorised Indian online seller, we match that price, before you order or within 7 days of ordering. The terms are on our lowest-price guarantee page.

What is the return policy?

For delivery in India, unused items in original packaging can be returned within 7 days of delivery, with free return shipping.
