Catalogue / Switchgear / Havells FP Switch Disconnector — 40 A
BrandHavells
CategorySwitchgear
SpecificationSwitchgears · Type Four Pole · Rated Frequency 50 Hz · Current Rating 63 A · Ambient Temperature -5 °C to +55 °C · Rated Current 40 A - 100 A · Terminal Capacity (Maximum) 35 mm²
SKUDHMXIFPX040
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 3–7 working days
Havells· In stock
Havells FP Switch Disconnector — 40 A
Rating: 40 A
₹802/pc+ 18% GST
₹946 incl. GST · MRP ₹1,30439% off
Wholesale · 15+ units
₹762 +GST /pc
Add to cart
Buy now
🚚 Delivered pan-India · 30-day NBFC credit is coming soon — join the waitlist.
Price history
Elume price over time. Market comparison appears once we track this item. Updated regularly.
ElumeMRP
Elume today
₹946
MRP
₹1,539
1 price point
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
3–7 working days to any site in India
📦
Wholesale built in
−5% auto-applies at 15+ units — ₹899/pc on this product
About this product
from havells.com- ETP Grade Copper
- Flame-Retardant Thermoplastic Material
- IP 20 Design
- Superior Air Circulation
- IS / IEC 60947-3
As published by Havells. Verify critical parameters against the datasheet before specifying.
Technical specifications
Havells Havells FP Switch Disconnector — 40 A · DHMXIFPX040
Device typeSwitch disconnector (isolator)
Current rating40 A
Reference standardIEC 60947-3
BrandHavells
SKUDHMXIFPX040
Sold asPer pc
TypeFour Pole
Net Contents1 N Main Unit
Net Quantity1 N
Product rangeSwitchgears
Rated Current40 A - 100 A
Manufactured ByHavells India Ltd.
Rated Frequency50 Hz
Protection ClassIP20
Shock Resistance40 mm free fall
Country Of OriginIndia
Mounting Din Rail35 mm x 7.5 mm
Rated Voltage (Ue)415 V
Ambient Temperature-5 °C to +55 °C
Standard ConformityIS / IEC 60947-3
Utilization CategoryAC 22 A
Installation PositionVertical / Horizontal
Rated Impulse Voltage4 kV
No. of Poles (Execution)2P, 4P
Rated Insulation Voltage690 V
Terminal Capacity (Maximum)35 mm²
Electrical / Mechanical Endurance (No. of Operations)10000
The full range · 3 options
Every option is its own product with live pricing — tap a row to switch.
| Option | Rating | Elume price (ex-GST) | MRP | Off |
|---|---|---|---|---|
| Havells FP Switch Disconnector — 100 A | 100 A | ₹1,074 | ₹1,747 | 39% |
| Havells FP Switch Disconnector — 63 AParent | 63 A | ₹856 | ₹1,393 | 39% |
| Havells FP Switch Disconnector — 40 AViewing | 40 A | ₹802 | ₹1,304 | 39% |
Know before you buy
Read: Top 10 MCBs & Switchgear in India (2026) →What is the difference between an MCB, an RCCB and an RCBO?
An MCB protects against overload and short circuit (overcurrent). An RCCB protects against earth leakage and electric shock by detecting current imbalance, typically at 30mA, but offers no overcurrent protection. An RCBO combines both functions in one module, giving overcurrent and earth-leakage protection per circuit, saving DIN-rail space.
Should I use a Type AC or Type A RCCB in India?
Type AC detects only AC earth leakage and suits basic resistive and inductive loads. Type A also detects pulsating DC leakage produced by electronics, EV chargers, inverters and LED drivers. Since most Indian homes now run such loads, Type A is the safer choice. Use Type B for solar inverters and variable-frequency drives.
What breaking capacity (kA) do I need for an Indian home?
Breaking capacity is the maximum fault current an MCB can safely interrupt. For most homes located some distance from the transformer, 6kA is adequate. For apartments, boards close to the distribution transformer, and commercial mains, specify 10kA or higher. Always base it on the actual prospective short-circuit current at your board.
Frequently asked questions
Is Havells FP Switch Disconnector — 40 A genuine and warranty-backed?
Yes. Every Havells product on Elume is 100% genuine, sourced through authorised channels, and carries the manufacturer's standard warranty.
Do you deliver across India?
Yes — we deliver pan-India, usually within 3–7 working days, and delivery is free.
Can I get a GST invoice?
Yes. Enter your GSTIN at checkout and we issue a GST invoice with tax shown separately, so businesses can claim input tax credit.
Is there a wholesale or bulk rate?
Yes. Orders of 15 or more pcs get a wholesale rate about 5% below the listed Elume price — shown on every product page.
What is the return policy?
Unused items in original packaging can be returned within 7 days of delivery, with free return shipping.
