ABB DSB201 M RCBO · 1P+N · 20 A · 300 mA · Type AC · C curve · 2CSR275075R3204: Elume price today ₹4,426 per pc incl. GST, 53% below the ₹9,377 MRP. The price has held steady for the last 30 days. The average price across the sellers we track is ₹2,928, ₹1,498 less than here.
ABB DSB201 M RCBO · 1P+N · 300 mA · 20 A · Type AC is a switchgear device from ABB. Key ratings: Poles 1P+N, Rated current 20 A, Sensitivity 300 mA.
An RCBO combines an MCB and an RCCB in one device, protecting a single circuit against overload, short circuit and earth leakage. An RCCB only handles earth leakage and needs separate MCBs (RCBOs are covered by IS 12640 (Part 2)).
With RCBOs, a leakage fault on one circuit trips only that circuit, so the rest of the house keeps power and it is easier to find the fault. They cost more and take more DB space than one RCCB with several MCBs, so many homes use RCBOs only on critical circuits like geyser, washing machine and outdoor points.
This RCBO trips on leakage at 300 mA, in addition to normal overload and short-circuit protection. 30mA is the usual choice for shock protection on final circuits.
Yes, an RCBO suits geysers, pumps and other loads in wet areas because it gives shock protection and overload protection on that one circuit. Choose the current rating and curve as you would for an MCB, based on the appliance's rated current and the cable, and have a licensed electrician confirm.
Yes. The RCBO compares phase and neutral current to detect leakage, so the circuit's neutral must pass through it and must not be shared with any other circuit.
RCBOs mount on the standard 35mm DIN rail, but many are 2 modules wide or need a separate neutral connection, so check that your DB has enough free ways and space. Some compact single-module RCBOs fit like an SP MCB; refer to the product's module width.
