ABB XT3S 250 TMD 250-2500 4p F F InN=100% · 1SDA068232R11SDA068232R1↓ 53% off MRP
BrandABB
CategorySwitchgear
SpecificationC.BREAKER TMAX XT3S 250 FIXED FOUR-POLE WITH FRONT TERMINALS AND THERMOMAGNETIC RELEASE TMD R 250-2500 A FULLY RATED NEUTRAL
Brand SKU1SDA068232R1
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 7 working days
ABB· In stock
Visit the ABB store

ABB XT3S 250 TMD 250-2500 4p F F InN=100% · 1SDA068232R1

₹30,891/pcincl. GST-53%
₹26,179 + 18% GST · MRP ₹65,447
Add to cart
Buy now
  • Secured by Razorpay · UPI, cards, net banking, wallets
  • GST invoice, claim input tax credit
  • Tracked delivery, 5 to 7 working days
✓ Full brand warranty on every order
✓Lowest price guarantee · found it cheaper? We match it.
💳 30 Day credit facility available launching soon - join waitlist.
₹30,891 /pc incl. GST
Delivery ₹1,000, ships insured

ABB XT3S 250 TMD 250-2500 4p F F InN=100% · 1SDA068232R1: Elume price today ₹30,891 per pc incl. GST, 53% below the ₹65,447 MRP. The price has held steady for the last 30 days. The average price across the sellers we track is ₹17,589, ₹13,302 less than here.

Price history
Elume price vs the average market price across the sellers we track, day by day. Tap a legend entry to show or hide a line.
25 May to 22 Nov
₹70,028₹56,475₹42,921₹29,368₹15,815₹65,447₹30,891₹17,589
May 26Jun 26Aug 26Sep 26Oct 26Nov 26Nov 26
Elume today
₹30,891
Avg market price
₹17,589
MRP
₹65,447
Lowest in view · 27 Aug
₹17,005
Highest in view · 3 Oct
₹30,891
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
7 working days to your location
📦
Wholesale built in
Wholesale price at 15+ units: ₹29,346/pc on this product, applied automatically

ABB XT3S 250 TMD 250-2500 4p F F InN=100% is an MCCB from ABB. It protects feeders and sub-mains against overload and short circuit and is the incomer or outgoing breaker of a panel. Key ratings: Poles 4P (FP), Rated current 250 A, Icu 50 kA, Release TMD, Setting range 175...250 A, Rated voltage 690 V AC. It is built to IEC60947-2.

As published by ABB. Verify critical parameters against the datasheet before specifying.
ABB ABB XT3S 250 TMD 250-2500 4p F F InN=100% · 1SDA068232R1 · 1SDA068232R1
Device typeMoulded case circuit breaker (MCCB)
SeriesSACE Tmax XT
Frame size250 A
Poles4P (FP)
Rated current250 A
Rated voltage690 V AC
Frequency50 / 60 Hz
Ultimate breaking capacity (Icu)50 kA
Service breaking capacity (Ics)36 kA
Setting range175...250 A
ReleaseTMD
Insulation voltage (Ui)800 V
Impulse withstand (Uimp)8 kV
Terminal capacityBusbar 85..192 mm²
Reference standardIEC60947-2
Net weight2.1 kg
Country of originItaly
Current rating2500 A
BrandABB
Brand SKU1SDA068232R1
ELINEP9KJCD4H9
Sold asPer pc
Ratings as published by ABB (abb.com product data, datasheet 1SDC210100D0206; Product name; shop.in.abb.com listing for 1SDA068232R1, 23 Sep 2026). Verify critical parameters against the datasheet before specifying.
Read: Contactor Sizing for 400 V and 415 V Motors: kW to Amps, AC-3 Ratings and Overload Relays →
What size contactor do I need for a 7.5 kW motor?
A 7.5 kW three-phase motor at 400 V draws about 14.5 A, so a contactor rated at least 16 to 18 A at AC-3 is the usual choice, with an overload relay set to the nameplate current.
What is the difference between AC-1 and AC-3?
AC-1 is the rating for resistive loads such as heaters; AC-3 is the rating for switching squirrel-cage motors in normal duty. Motors are always sized on the AC-3 figure, which is lower.
How many amps per kW for a three-phase motor?
At 400 V, roughly 2 A per kW for small motors, falling towards about 1.8 A per kW above 30 kW, because larger motors run at a better power factor and efficiency. Use the nameplate for the exact figure.
When do I need an MCCB instead of an MCB?

MCBs typically go up to 63A or 125A, so MCCBs are used for higher currents (roughly 16A to 1600A), as main incomers of buildings, panels and sub-panels, or where higher breaking capacity and adjustable settings are needed. MCCBs are covered by IS/IEC 60947-2.

What is the difference between Icu and Ics?

Icu is the ultimate breaking capacity the MCCB can interrupt once, while Ics is the service breaking capacity it can interrupt and still remain usable. Choose an MCCB whose Icu exceeds the prospective fault current at the installation point; for critical feeders, a higher Ics (ideally 100% of Icu) is preferred.

Should I take a 3 pole or 4 pole MCCB?

Use 3 pole where only the phases need switching, and 4 pole where the neutral must also be isolated, such as generator changeover systems, incomers with unbalanced single-phase loads or where local rules require neutral isolation. Your panel designer or electrician should decide based on the earthing system.

Can I adjust the current setting of an MCCB?

Many MCCBs have an adjustable overload setting (for example 0.8 to 1 times the frame rating, or wider on electronic releases), and some allow short-circuit adjustment too. Fixed-release MCCBs cannot be adjusted, so check the release type before buying.

What accessories can be added to an MCCB?

Common add-ons include auxiliary and trip alarm contacts, shunt trip and undervoltage releases, rotary handles for door mounting, motor operators for remote switching, and terminal spreaders or extended terminals for larger cables. Accessories are usually specific to the brand and frame size.
