ABB AX32-30-01-86 400-415V50Hz/415 V-440V60Hz Contactor · 1SBL281074R86011SBL281074R8601↓ 53% off MRP
BrandABB
CategorySwitchgear
SpecificationContactor · 3P (TP) · Auxiliary Circuit 690 V
Brand SKU1SBL281074R8601
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 7 working days
ABB· In stock
Visit the ABB store

ABB AX32-30-01-86 400-415V50Hz/415 V-440V60Hz Contactor · 1SBL281074R8601

₹4,510/pcincl. GST-53%
₹3,822 + 18% GST · MRP ₹9,555
Add to cart
Buy now
  • Secured by Razorpay · UPI, cards, net banking, wallets
  • GST invoice, claim input tax credit
  • Tracked delivery, 5 to 7 working days
✓ Full brand warranty on every order
✓Lowest price guarantee · found it cheaper? We match it.
💳 30 Day credit facility available launching soon - join waitlist.
₹4,510 /pc incl. GST
Free pan-India delivery

ABB AX32-30-01-86 400-415V50Hz/415 V-440V60Hz Contactor · 1SBL281074R8601: Elume price today ₹4,510 per pc incl. GST, 53% below the ₹9,555 MRP. The price has held steady for the last 30 days. The average price across the sellers we track is ₹3,093, ₹1,417 less than here. The lowest tracked seller lists it at ₹3,093, ₹1,417 below it (tell us and we match it).

Price history
Elume price vs the average market price across the sellers we track, day by day. Tap a legend entry to show or hide a line.
25 May to 22 Nov
₹10,224₹8,373₹6,521₹4,670₹2,819₹9,555₹4,510₹3,093
May 26Jun 26Aug 26Sep 26Oct 26Nov 26Nov 26
Elume today
₹4,510
Avg market price
₹3,093
MRP
₹9,555
Lowest in view · 10 Aug
₹3,031
Highest in view · 3 Oct
₹4,510
For panel builders
Buying this for a panel?
The price above is for a single piece. Send the whole BOM in any file and a person quotes the job within 24 hours.
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
7 working days to your location
📦
Wholesale built in
Wholesale price at 15+ units: ₹4,285/pc on this product, applied automatically

AX32, AX40 contactors are mainly used for controlling 3-phase motors and power circuits up to 690 V AC. These contactors are of the block type design with: – 3 main poles and 1 built-in auxiliary contact – control circuit: AC operated – add-on auxiliary contact blocks for front or side mounting and a wide range of accessories.

As published by ABB. Verify critical parameters against the datasheet before specifying.
ABB ABB AX32-30-01-86 400-415V50Hz/415 V-440V60Hz Contactor · 1SBL281074R8601 · 1SBL281074R8601
Device typeContactor
Poles3P (TP)
Rated voltageAuxiliary Circuit 690 V
FrequencyAuxiliary Circuit 50 / 60 Hz
Insulation voltage (Ui)acc. to IEC 60947-4-1 and VDE 0110 (Gr. C) 690 V
Impulse withstand (Uimp)Auxiliary Circuit 6 kV
Width3 modules (54 mm)
Ingress protectionIP20
Net weight0.667 kg
Country of originBulgaria
Reference standardIS/IEC 60898-1
BrandABB
Brand SKU1SBL281074R8601
ELINE376K3RRGH
Sold asPer pc
Ratings as published by ABB (abb.com product data, datasheet 1SBC100187L0203; shop.in.abb.com listing for 1SBL281074R8601, 23 Sep 2026). Verify critical parameters against the datasheet before specifying.
Read: Contactor Sizing for 400 V and 415 V Motors: kW to Amps, AC-3 Ratings and Overload Relays →
What size contactor do I need for a 7.5 kW motor?
A 7.5 kW three-phase motor at 400 V draws about 14.5 A, so a contactor rated at least 16 to 18 A at AC-3 is the usual choice, with an overload relay set to the nameplate current.
What is the difference between AC-1 and AC-3?
AC-1 is the rating for resistive loads such as heaters; AC-3 is the rating for switching squirrel-cage motors in normal duty. Motors are always sized on the AC-3 figure, which is lower.
How many amps per kW for a three-phase motor?
At 400 V, roughly 2 A per kW for small motors, falling towards about 1.8 A per kW above 30 kW, because larger motors run at a better power factor and efficiency. Use the nameplate for the exact figure.
How do I choose a contactor for my motor?

Select by the contactor's AC-3 current (or kW) rating at your supply voltage, which should be at least the motor's full-load current from the nameplate. Do not go by the higher AC-1 rating, which applies only to resistive loads (contactors are covered by IS/IEC 60947-4-1).

What is the difference between AC-1 and AC-3 rating?

AC-1 is for non-inductive or slightly inductive loads like heaters, while AC-3 is for starting and stopping squirrel cage motors. The same contactor has a much lower AC-3 rating than AC-1, and AC-4 (inching or plugging) is even more demanding.

Does a contactor protect the motor?

No. A contactor only switches the motor on and off; overload protection needs a thermal overload relay and short-circuit protection needs an MPCB, MCB, MCCB or fuses upstream.

Why is my contactor humming or chattering?

Common causes are low or fluctuating control voltage, a wrong coil voltage, dust or rust on the magnet faces, or a broken shading ring. Check the supply at the coil terminals first, then clean or replace the contactor if needed.

How many auxiliary contacts does this have and can I add more?

Most contactors have built-in auxiliary contacts (NO and/or NC) for holding and interlocking circuits, and many allow add-on auxiliary blocks on the front or side. Check the contact configuration and add-on compatibility in the product details.

How many contactors do I need for a star-delta starter?

A star-delta starter uses three contactors (main, delta and star), a star-delta timer and an overload relay. The main and delta contactors are typically sized at about 58% of the motor current and the star contactor smaller, as per the manufacturer's selection table.
