Schneider ComPacT NSX100H MCCB · 3P · 50 A · 100 kA · TM-DC10H3TM050↓ 1% off MRP1 / 6
BrandSchneider
CategorySwitchgear
Brand SKUC10H3TM050
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 3–7 working days
Schneider· In stock
Visit the Schneider store

Schneider ComPacT NSX100H MCCB · 3P · 50 A · 100 kA · TM-D

Rating: 50 A
Poles: 3P
NEW added this week
₹44,765/pcincl. GST-1%
₹37,936 + 18% GST · MRP ₹45,218
Add to cart
Buy now
  • Secured by Razorpay · UPI, cards, net banking, wallets
  • GST invoice with every order
  • Tracked delivery, 3 to 7 working days
✓ Full brand warranty on every order
✓Lowest price guarantee · found it cheaper? We match it.
💳 30 Day credit facility available launching soon - join waitlist.
₹44,765 /pc incl. GST
Delivery ₹1,000, ships insured

Schneider ComPacT NSX100H MCCB · 3P · 50 A · 100 kA · TM-D: Elume price today ₹44,765 per pc incl. GST, 1% below the ₹45,218 MRP. The price has held steady for the last 30 days.

Price history
Elume price over time, day by day. Market comparison appears once we track this item.
13 Oct to 19 Oct
₹48,383₹46,695₹45,007₹43,319₹41,631₹45,218₹44,765
13 Oct14 Oct15 Oct16 Oct17 Oct18 Oct19 Oct
Elume today
₹44,765
MRP
₹45,218
Lowest in view · 17 Oct
₹44,765
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
3–7 working days to any site in India
📦
Wholesale built in
−5% auto-applies at 15+ units - ₹42,527/pc on this product

This ComPacT NSX100H is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 70kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 50A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX100H is part of Schneider Electric EcoStruxure Power architecture.

As published by Schneider. Verify critical parameters against the datasheet before specifying.
Schneider Schneider ComPacT NSX100H MCCB · 3P · 50 A · 100 kA · TM-D · C10H3TM050
Poles3P
Rated current50 A
Breaking capacity100 kA
Ingress protectionIP40
Reference standardEN/IEC 60947-2
Net weight2.05 kg
Device typeMiniature circuit breaker (MCB)
Current rating50 A
BrandSchneider
Brand SKUC10H3TM050
ELINEM736RJKMR
Sold asPer pc
RangeComPacT
Depth (D)86 mm
Width (W)105 mm
Height (H)161 mm
Control typeToggle
Network typeAC
Product nameComPacT NSX
Trip unit nameTM-D
Number of slots5 slot(s)
Protection typeL : for overload protection (thermal) · I : for short-circuit protection (magnetic)
Connection pitch35 mm
Mounting supportBackplate
Trip unit rating50 A at 40 °C
Device short nameNSX100H
Mounting positionHorizontal and vertical · Flat on the back
Network frequency50/60 Hz
Poles description3P
Upside connectionFront
Device applicationDistribution
[In] rated current50 A at 40 °C
Downside connectionFront
Trip unit technologyThermal-magnetic
Utilisation categoryCategory A
Electrical durability50000 cycles at 440 V In/2 · 30000 cycles at 440 V In · 20000 cycles at 690 V In/2 · 10000 cycles at 690 V In
Mechanical durability50000 cycles
Breaking capacity codeH 70 kA 415 V AC
Earth-leakage protectionWithout
Product or component typeCircuit breaker
Suitability for isolationYes conforming to EN/IEC 60947-2
Power dissipation per pole4.11 W
Protected poles description3D
Circuit breaker mounting modeFixed
[Ui] rated insulation voltage800 V AC 50/60 Hz
Trip unit protection functionsLI
[Ue] rated operational voltage690 V AC 50/60 Hz
[Ics] rated service breaking capacity100 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 · 70 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 · 65 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 · 50 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2 · 35 kA at 525 V AC 50/60 Hz conforming to IEC 60947-2 · 10 kA at 660/690 V AC 50/60 Hz conforming to IEC 60947-2
[tr] long-time delay adjustment range120…400 s at 1.5 x In · 15 s at 6 x Ir
[Uimp] rated impulse withstand voltage8 kV
Long-time protection delay adjustment type trFixed
[Ir] long-time protection pick-up adjustment range0.7...1 x In
Instantaneous protection pick-up adjustment type IiFixed
[Ii] instantaneous protection pick-up adjustment range500 A
Long-time pick-up adjustment type Ir (thermal protection)Adjustable
Ratings as published by Schneider (se.com). Verify critical parameters against the datasheet before specifying.
