Schneider Harmony Control Relay · 1 C/O · IP20 · RM17UBE15RM17UBE15↓ 1% off MRP1 / 12
BrandSchneider
CategoryIndustrial Control
Specification1 C/O
Brand SKURM17UBE15
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 3–7 working days
Schneider· In stock
Visit the Schneider store

Schneider Harmony Control Relay · 1 C/O · IP20 · RM17UBE15

NEW added this week
₹32,245/pcincl. GST-1%
₹27,326 + 18% GST · MRP ₹32,570
Add to cart
Buy now
  • Secured by Razorpay · UPI, cards, net banking, wallets
  • GST invoice with every order
  • Tracked delivery, 3 to 7 working days
✓ Full brand warranty on every order
✓Lowest price guarantee · found it cheaper? We match it.
💳 30 Day credit facility available launching soon - join waitlist.
₹32,245 /pc incl. GST
Delivery ₹1,000, ships insured

Schneider Harmony Control Relay · 1 C/O · IP20 · RM17UBE15: Elume price today ₹32,245 per pc incl. GST, 1% below the ₹32,570 MRP. The price has held steady for the last 30 days.

Price history
Elume price over time, day by day. Market comparison appears once we track this item.
14 Oct to 20 Oct
₹34,850₹33,634₹32,419₹31,203₹29,988₹32,570₹32,245
14 Oct15 Oct16 Oct17 Oct18 Oct19 Oct20 Oct
Elume today
₹32,245
MRP
₹32,570
Lowest in view · 17 Oct
₹32,245
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
3–7 working days to any site in India
📦
Wholesale built in
−5% auto-applies at 15+ units - ₹30,633/pc on this product

This Harmony RM17-UB relay allows monitoring of voltage control in single phase networks. This modular multi function single phase voltage control relay is ideal for monitoring of electrical values in industrial and building control panels. It applies to a wide type of industrial automation applications such as hoisting, packaging, lifts, textile, water. It has one of market slimmest form-factors with 17.5mm width, allowing for a flexible and easy installation on DIN rail, using the same space as any modular 1-pole DIN device. It also offers a sealable cover, simple and precise settings with screw trimmers. It provides automatic shutdown management and fault information to user for a quick fault identification and troubleshooting. multi function controller for wide choice selected in hard-wired logic automated systems, ideal for refurbishment of old installations without using a PLC.

As published by Schneider. Verify critical parameters against the datasheet before specifying.
Schneider Schneider Harmony Control Relay · 1 C/O · IP20 · RM17UBE15 · RM17UBE15
Ingress protectionIP20 (terminals)· IP30 (casing)
Reference standardIEC 60255-6
Net weight0.09 kg
BrandSchneider
Brand SKURM17UBE15
ELINEHHH27FHHD
Sold asPer pc
PolarityNon reversible polarity on DC supply
StandardsIEC 60255-6
Directives73/23/EEC - low voltage directive · 89/336/EEC - electromagnetic compatibility
Hysteresis5 % fixed of threshold setting
Relay nameRM17UBE
Relay typeVoltage control relay
Reset time1500 ms time delay
Control typeWithout test button
Power on delay1000 ms DC · 500 ms AC
Quality labelsCE
Output contacts1 C/O
Repeat accuracy+/- 0.5 % for input and measurement circuit · +/- 1 % for time delay
Time delay typeAdjustable 0.1...10 s, 0 + 10 % Tt- time delay upon fault
Pollution degree3 conforming to IEC 60664-1
Range of productHarmony Control Relays
Measurement range65...260 V AC/DC
Relative humidity95 % at 55 °C conforming to IEC 60068-2-30
Measurement accuracy+/- 10 % of the full scale value
Overvoltage categoryIII conforming to IEC 60664-1
Electrical durability100000 cycles
Insulation resistance> 500 MOhm at 500 V DC conforming to IEC 60255-5
Mechanical durability30000000 cycles
Supply voltage limits50…270 V AC/DC
Product certificationsUL · GL · GOST · C-Tick · CSA
nominal output current5 A
Dielectric test voltage2 kV, 1 min AC 50 Hz conforming to IEC 60255-5
IP degree of protectionIP20 (terminals) conforming to IEC 60529 · IP30 (casing) conforming to IEC 60529
Maximum measuring cycle150 ms measurement cycle as true rms value
Power consumption in VA0…3 VA AC
Switching capacity in VA1250 VA
Control circuit frequency50...60 Hz +/- 10 %
Maximum switching current5 A AC/DC
Maximum switching voltage250 V AC/DC
Minimum switching current10 mA at 5 V DC
Product or component typeVoltage control relay
[Us] rated supply voltage, self-powered
Relay monitored parametersOvervoltage and undervoltage detection
Product specific applicationFor single-phase and DC supply
Contacts type and composition1 C/O
Electromagnetic compatibilityEmission standard for industrial environments conforming to IEC 61000-6-4 · Emission standard for residential, commercial and light-industrial environments conforming to IEC 61000-6-3 · Immunity for industrial environments conforming to NF EN/IEC 61000-6-2
[Ui] rated insulation voltage250 V conforming to IEC 60664-1
Maximum power consumption in W1 W DC
Setting accuracy of time delay10 %
Ambient air temperature for storage-40…70 °C · -40…70 °C
Ambient air temperature for operation-20…50 °C
Ratings as published by Schneider (se.com). Verify critical parameters against the datasheet before specifying.
