Schneider Zelio Logic Analogue I/O Extension Module · 4 I O · 24 V DC · for Zelio LogicSR3XT43BD↓ 1% off MRP1 / 6
BrandSchneider
CategoryIndustrial Control
Brand SKUSR3XT43BD
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 3–7 working days
Schneider· In stock
Visit the Schneider store

Schneider Zelio Logic Analogue I/O Extension Module · 4 I O · 24 V DC · for Zelio Logic

NEW added this week
₹27,578/pcincl. GST-1%
₹23,371 + 18% GST · MRP ₹27,856
Add to cart
Buy now
  • Secured by Razorpay · UPI, cards, net banking, wallets
  • GST invoice with every order
  • Tracked delivery, 3 to 7 working days
✓ Full brand warranty on every order
✓Lowest price guarantee · found it cheaper? We match it.
💳 30 Day credit facility available launching soon - join waitlist.
₹27,578 /pc incl. GST
Delivery ₹1,000, ships insured

Schneider Zelio Logic Analogue I/O Extension Module · 4 I O · 24 V DC · for Zelio Logic: Elume price today ₹27,578 per pc incl. GST, 1% below the ₹27,856 MRP. The price has held steady for the last 30 days.

Price history
Elume price over time, day by day. Market comparison appears once we track this item.
14 Oct to 20 Oct
₹29,806₹28,766₹27,727₹26,687₹25,648₹27,856₹27,578
14 Oct15 Oct16 Oct17 Oct18 Oct19 Oct20 Oct
Elume today
₹27,578
MRP
₹27,856
Lowest in view · 17 Oct
₹27,578
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
3–7 working days to any site in India
📦
Wholesale built in
−5% auto-applies at 15+ units - ₹26,199/pc on this product

This product is part of the Zelio Logic range, an offer of smart relays for simple automation systems from 10 to 40 I/Os. The analogue I/O extension module provides 2 input/outputs. It is an extension module with an analogue output range of 0 to 10V and a maximum load current of 10mA for analogue output. It provides 10bit on the input range and 10bit on the output range. The temperature probe is Pt 100, 3-wire conforming to IEC 751. It is furnished with screw terminal for electrical connections. It is an IP20 and IP40 rated product. It weighs 0.11kg. This product meets EN/IEC 61000-4-12, EN/IEC 61000-4-5, EN/IEC 61000-4-3, EN/IEC 61000-4-4 level 3, EN/IEC 61000-4-6 level 3, EN/IEC 61000-4-2 level 3, EN/IEC 60068-2-6 Fc, EN/IEC 61000-4-11 and EN/IEC 60068-2-27 Ea standards. Simple to select, install and program, Zelio Logic is suitable for all your applications. Flexible, it offers you the choice of 2 ranges, compact or modular, extendable and 2 programming languages (FBD or LADDER). Easy to use, Zelio Logic provides a real alternative to solutions based on cabled logic or specific cards.

As published by Schneider. Verify critical parameters against the datasheet before specifying.
Schneider Schneider Zelio Logic Analogue I/O Extension Module · 4 I O · 24 V DC · for Zelio Logic · SR3XT43BD
Ingress protectionIP20 (terminal block)· IP40 (front panel)
Reference standardIEC 61000-4-12
Net weight0.11 kg
BrandSchneider
Brand SKUSR3XT43BD
ELINEFKK7M66JP
Sold asPer pc
LSB value0.15 °C, - 25...125 °C for analogue input circuit · 20 µA, 0...20 mA for analogue input circuit · 9.8 mV, 0...10 V for analogue input circuit · 9.8 mV, 0...10 V for analogue output
Load typeResistive load for analogue output
StandardsIEC 61000-4-12 · IEC 61000-4-5 · IEC 61000-4-3 · IEC 61000-4-4 level 3 · IEC 61000-4-6 level 3 · IEC 61000-4-2 level 3 · IEC 60068-2-6 Fc · IEC 61000-4-11 · IEC 60068-2-27 Ea
Conversion timeSmart relay cycle time for analogue input circuit · Smart relay cycle time for analogue output
Input impedance18 kOhm, input range: 0...10 V for analogue input circuit · 247 Ohm, input range: 0...20 mA for analogue input circuit
Repeat accuracy< +/- 0.3 °C, input range: - 25...125 °C at 25 °C for analogue input circuit · <= +/- 1 %, input range: 0...10 V at 25 °C for analogue input circuit · <= +/- 1 %, input range: 0...10 V at 55 °C for analogue output · <= +/- 1 %, input range: 0...20 mA at 25 °C for analogue input circuit
Conversion error+/- 1 % of the full scale value, input range: 0...10 V (25 °C) for analogue output · +/- 1 % of the full scale value, input range: 0...10 V (55 °C) for analogue output · +/- 1 %, input range: 0...10 V (25 °C) for analogue input circuit · +/- 1 %, input range: 0...10 V (55 °C) for analogue input circuit · +/- 1 %, input range: 0...20 mA (25 °C) for analogue input circuit · +/- 1 %, input range: 0..
Pollution degree2 conforming to IEC 61131-2
Range of productZelio Logic
Relative humidity95 % without condensation or dripping water
tightening torque0.5 N.m
Operating altitude2000 m
Operating distance10 m with screened cable for analogue input circuit · 10 m with screened cable for analogue output
Analogue input typeCommon mode
Analogue input range0...10 V · 0...20 mA · -25...125 °C
Maximum load current10 mA for analogue output
Analogue input number2
Analogue output range0...10 V
Analogue output number2
Product certificationsGOST · UL · C-Tick · CSA
Temperature probe typePt 100, 3-wire conforming to IEC 751
Connections - terminalsScrew terminals, 1 x 0.25...1 x 2.5 mm² (24 AWG...14 AWG) semi-solid · Screw terminals, 1 x 0.25...1 x 2.5 mm² (24 AWG...14 AWG) solid · Screw terminals, 2 x 0.25...2 x 1.5 mm² (23 AWG...16 AWG) solid · Screw terminals, 1 x 0.25...1 x 2.5 mm² (24 AWG...14 AWG) flexible with cable end · Screw terminals, 2 x 0.25...2 x 0.75 mm² (24 AWG...18 AWG) flexible with cable end
IP degree of protectionIP20 (terminal block) conforming to IEC 60529 · IP40 (front panel) conforming to IEC 60529
Short-circuit protectionWith analogue output
Analogue input resolution10 bits on the input range
Product or component typeAnalogue I/O extension module
Analogue output resolution10 bits on the output range
Maximum altitude transport3048 m
Maximum permissible voltage30 V for analogue input circuit
Reverse polarity protectionAnalogue input circuit: with
Environmental characteristicEMC directive conforming to IEC 61000-6-2 · EMC directive conforming to IEC 61000-6-3 · EMC directive conforming to IEC 61000-6-4 · EMC directive conforming to IEC 61131-2 zone B · Low voltage directive conforming to IEC 61131-2
Disturbance radiated/conductedClass B conforming to IEC 55022-11 Group 1
[Imp] maximum permanent current30 mA for analogue input circuit
Ambient air temperature for storage-40…70 °C
Ambient air temperature for operation-20…40 °C conforming to IEC 60068-2-1 and IEC 60068-2-2 · -20…55 °C conforming to IEC 60068-2-1 and IEC 60068-2-2
Ratings as published by Schneider (se.com). Verify critical parameters against the datasheet before specifying.
