Legrand DX3 Isolator · 3P (TP) · 32 A · 406509406509↓ 33% off MRP1 / 3
BrandLegrand
CategorySwitchgear
SpecificationIsolator · 3P (TP) · 32 A
Brand SKU406509
AvailabilityReady to ship · Only 5 left · Ships tomorrow
DeliveryPan-India · 5 working days
Legrand· Ready to ship
Visit the Legrand store

Legrand DX3 Isolator · 3P (TP) · 32 A · 406509

₹1,059/pcincl. GST-33%
₹897 + 18% GST · MRP ₹1,574
Add to cart
Buy now
Ready to shipOnly 5 left
Ships tomorrow. Delivery by Sat, 28 Nov.
In Delhi NCR? Get it today. Order before 1 pm for delivery the same day, after that the next day, for ₹400 extra. Choose Delhi NCR express at checkout.
  • Secured by Razorpay · UPI, cards, net banking, wallets
  • GST invoice, claim input tax credit
  • Tracked delivery, 5 to 7 working days
✓ Full brand warranty on every order
✓Lowest price guarantee · found it cheaper? We match it.
💳 30 Day credit facility available launching soon - join waitlist.
₹1,059 /pc incl. GST
Free delivery over ₹4,000

Legrand DX3 Isolator · 3P (TP) · 32 A · 406509: Elume price today ₹1,059 per pc incl. GST, 33% below the ₹1,574 MRP. The price has held steady for the last 30 days. The average price across the sellers we track is ₹856, ₹203 less than here. The lowest tracked seller lists it at ₹856, ₹203 below it (tell us and we match it).

Price history
Elume price vs the average market price across the sellers we track, day by day. Tap a legend entry to show or hide a line.
24 Aug to 22 Nov
₹2,106₹1,776₹1,447₹1,117₹788₹1,574₹1,059₹856
24 Aug11 Sep29 Sep17 Oct4 Nov22 Nov
Elume today
₹1,059
Avg market price
₹856
MRP
₹1,574
Lowest in view · 7 Oct
₹847
Highest in view · 23 Oct
₹1,059
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
7 working days to your location
📦
Wholesale built in
Wholesale price at 15+ units: ₹1,006/pc on this product, applied automatically

Legrand DX3-TP 32A Isolator

As published by Legrand. Verify critical parameters against the datasheet before specifying.
Legrand Legrand DX3 Isolator · 3P (TP) · 32 A · 406509 · 406509
Device typeIsolator (switch disconnector)
SeriesDX3
Poles3P (TP)
Rated current32 A
Warranty5 years if mounted inside Legrand DB
Country of originIndia
Current rating32 A
Reference standardIEC 60947-3
BrandLegrand
Brand SKU406509
ELINE9JJ7DFMMC
Sold asPer pc
ColorRAL7035
Product Code406509
Product features➥Isolators for AC applications upto 125 A➥ISI marked as per IEC 60947-3➥Integrated label holder➥Ergonomic red color dolly➥Sliding bottom clamp➥Double break mechanism➥Improved air channels➥Color coded On/Off indication on dolly➥Biconnect lower terminals➥IP 20 protected terminals➥Sliding shutters 1 module per pole Rated Current: 32A Rated Operational Voltage:415 V ~ Design and manufacture of packaging compliant with decree 98-638 of 20/07/98 and Directive 94/62/EC.
Mechanism / AccessoriesMechanism
Ratings as published by Legrand (shop.legrand.co.in). Verify critical parameters against the datasheet before specifying.
Other Legrand ranges and models in this category, closest in price to this one.
Read: Contactor Sizing for 400 V and 415 V Motors: kW to Amps, AC-3 Ratings and Overload Relays →
What size contactor do I need for a 7.5 kW motor?
A 7.5 kW three-phase motor at 400 V draws about 14.5 A, so a contactor rated at least 16 to 18 A at AC-3 is the usual choice, with an overload relay set to the nameplate current.
What is the difference between AC-1 and AC-3?
AC-1 is the rating for resistive loads such as heaters; AC-3 is the rating for switching squirrel-cage motors in normal duty. Motors are always sized on the AC-3 figure, which is lower.
How many amps per kW for a three-phase motor?
At 400 V, roughly 2 A per kW for small motors, falling towards about 1.8 A per kW above 30 kW, because larger motors run at a better power factor and efficiency. Use the nameplate for the exact figure.
What is the difference between an isolator and an MCB?

An isolator (switch-disconnector) only switches the circuit on and off and does not trip on overload or short circuit, while an MCB provides protection. Isolators are used as main switches in DBs or near equipment for safe maintenance, and must be backed by a suitable MCB, MCCB or fuse.

Can I use an isolator as the main switch in my DB?

Yes, a DP isolator for single-phase or 4P isolator for three-phase is commonly used as the DB incomer, provided protection is given upstream (by the meter-side fuse or MCB) and on each outgoing circuit. Its current rating should be equal to or higher than the upstream protection rating.

Is this isolator safe to switch on load?

Switch-disconnectors to IS/IEC 60947-3 are rated for switching under load according to their utilisation category, such as AC-22 for mixed resistive and inductive loads or AC-23 for motor loads. Check the category on the product before using it to switch motors directly.

2 pole or 4 pole isolator - which one do I need?

Use 2 pole for single-phase supply (phase and neutral) and 4 pole for three-phase supply with neutral, so all live conductors are disconnected during maintenance. A 3 pole isolator is used where no neutral is switched, such as some motor feeders.

Can an isolator be locked off for maintenance?

Many isolators and rotary switch-disconnectors have a padlocking provision in the OFF position so no one can switch them on while work is in progress. Check for the lock-off feature if it is needed for your site's safety procedures.
