Schneider Harmony Timing Relay · 1 C/ORE10RMMU↓ 1% off MRP1 / 7
BrandSchneider
CategoryIndustrial Control
Brand SKURE10RMMU
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 3–7 working days
Schneider· In stock
Visit the Schneider store

Schneider Harmony Timing Relay · 1 C/O

NEW added this week
₹3,495/pcincl. GST-1%
₹2,962 + 18% GST · MRP ₹3,531
Add to cart
Buy now
  • Secured by Razorpay · UPI, cards, net banking, wallets
  • GST invoice with every order
  • Tracked delivery, 3 to 7 working days
✓ Full brand warranty on every order
✓Lowest price guarantee · found it cheaper? We match it.
💳 30 Day credit facility available launching soon - join waitlist.
₹3,495 /pc incl. GST
Free delivery over ₹4,000

Schneider Harmony Timing Relay · 1 C/O: Elume price today ₹3,495 per pc incl. GST, 1% below the ₹3,531 MRP. The price has held steady for the last 30 days.

Price history
Elume price over time, day by day. Market comparison appears once we track this item.
13 Oct to 19 Oct
₹3,778₹3,646₹3,514₹3,382₹3,250₹3,531₹3,495
13 Oct14 Oct15 Oct16 Oct17 Oct18 Oct19 Oct
Elume today
₹3,495
MRP
₹3,531
Lowest in view · 17 Oct
₹3,495
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
3–7 working days to any site in India
📦
Wholesale built in
−5% auto-applies at 15+ units - ₹3,320/pc on this product

Schneider Harmony Timing Relay · 1 C/O from Schneider Electric.

As published by Schneider. Verify critical parameters against the datasheet before specifying.
Schneider Schneider Harmony Timing Relay · 1 C/O · RE10RMMU
Ingress protectionIP20 terminal block:· IP40 housing:· IP50 front panel:
Reference standardIEC 60669-2-3
Net weight0.06 kg
BrandSchneider
Brand SKURE10RMMU
ELINEGHDHPRM69
Sold asPer pc
MarkingCE
StandardsIEC 60669-2-3 · EN 50082-1/2 · EN 50081-1/2 · IEC 61812-1
Directives93/68/EEC - low voltage directive · 73/23/EEC - low voltage directive · 89/336/EEC - electromagnetic compatibility
Reset time100 ms on de-energisation
Control typeSelector switch front panel
Voltage drift+/- 0.2 %/V
Voltage range0.85...1.1 Us
Component nameRE11R
On-load factor100 %
Repeat accuracy+/- 0.5 % conforming to IEC 61812-1
Time delay typeD · H · B · Ht · Ac · Bw · C · Di · At · A
Housing materialPolycarbonate
Local signallingLED indicator green, flashing for timing in progress · LED indicator green, steady for relay energised, no timing in progress · LED indicator green, blinking for relay energised, no timing in progress (except functions Di-D)
Mounting support35 mm symmetrical mounting rail conforming to EN 50022
Range of productHarmony Relay
Time delay range10...100 h · 0.1...1 s · 1...10 h · 6...60 s · 1...10 s · 1...10 min · 6...60 min
Contacts materialAgNi (cadmium free)
Creepage distance4 kV/3 conforming to IEC 60664-1
Temperature drift+/- 0.05 %/°C
breaking capacity2000 VA
Compatibility codeRE10
Dielectric strength2.5 kV for 1 mA/1 minute at 50 Hz conforming to IEC 61812-1
Discrete output typeRelay
Electrical durability100000 cycles at 8 A, 250 V for resistive load
Mechanical durability5000000 cycles
Width pitch dimension17.5 mm
Minimum pulse duration100 ms with load in parallel · 30 ms
Power consumption in W0.6 W at 24 V · 1.5 W at 240 V
Product certificationsCSA · GL · cULus
nominal output current8 A
Connections - terminalsScrew terminals, 2 x 1.5 mm² without cable end
IP degree of protectionIP20 terminal block: conforming to IEC 60529 · IP40 housing: conforming to IEC 60529 · IP50 front panel: conforming to IEC 60529
Immunity to microbreaks10 ms
Power consumption in VA32 VA at 240 V
Maximum switching current8 A
Maximum switching voltage250 V
Product or component typeModular timing relay
[Us] rated supply voltage24 V DC · 24...240 V AC 50/60 Hz
minimum switching current10 mA
Contacts type and composition1 C/O
Setting accuracy of time delay+/- 10 % of full scale at 25 °C conforming to IEC 61812-1
Ambient air temperature for storage-30…60 °C
Ambient air temperature for operation-20…60 °C
[Uimp] rated impulse withstand voltage5 kV for 1.2…50 µs conforming to IEC 60664-1 · 5 kV for 1.2…50 µs conforming to IEC 61812-1
Ratings as published by Schneider (se.com). Verify critical parameters against the datasheet before specifying.
Is Schneider Harmony Timing Relay · 1 C/O genuine and warranty-backed?

Yes. Every Schneider product on Elume is 100% genuine, sourced through authorised channels, and carries the manufacturer's standard warranty.

Do you deliver across India?

Yes. We deliver anywhere in India our couriers serve, usually within 3 to 7 working days from order confirmation. The delivery charge follows the order value (the GST-inclusive goods total after any discount code): ₹200 under ₹2,000; ₹100 from ₹2,000 to under ₹4,000; free from ₹4,000 to ₹25,000; ₹1,000 above ₹25,000, because large orders ship insured, often in several boxes. Heavy consignments add ₹1,000 for every started 10 kg beyond the first 10 kg of the order's total shipping weight, even when delivery is free. A free-delivery code makes the whole delivery charge zero. Every charge is shown at checkout before you pay.

Can I get a GST invoice?

Yes, on orders delivered in India. Enter your GSTIN at checkout and we issue a GST invoice with tax shown separately, so businesses can claim input tax credit.

Is there a wholesale or bulk rate?

Yes. Orders of 15 or more pcs get a wholesale rate about 5% below the listed Elume price, shown on every product page.

What if I find it cheaper somewhere else?

Tell us. If the same Schneider product is listed for less, GST and delivery included, by an authorised Indian online seller, we match that price, before you order or within 7 days of ordering. The terms are on our lowest-price guarantee page.

What is the return policy?

For delivery in India, unused items in original packaging can be returned within 7 days of delivery, with free return shipping.
