Schneider TeSys LC1D Power Contactor · 3P · 80 A AC-3 · 1 NO + 1 NC aux · 380 V AC coilLC1D65AQ7↓ 1% off MRP1 / 5
BrandSchneider
CategoryIndustrial Control
Brand SKULC1D65AQ7
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 3–7 working days
Schneider· In stock
Visit the Schneider store

Schneider TeSys LC1D Power Contactor · 3P · 80 A AC-3 · 1 NO + 1 NC aux · 380 V AC coil

Rating: 80 A AC-3
Coil: 380 V AC coil
NEW added this week
₹32,663/pcincl. GST-1%
₹27,681 + 18% GST · MRP ₹32,993
Add to cart
Buy now
  • Secured by Razorpay · UPI, cards, net banking, wallets
  • GST invoice with every order
  • Tracked delivery, 3 to 7 working days
✓ Full brand warranty on every order
✓Lowest price guarantee · found it cheaper? We match it.
💳 30 Day credit facility available launching soon - join waitlist.
₹32,663 /pc incl. GST
Delivery ₹1,000, ships insured

Schneider TeSys LC1D Power Contactor · 3P · 80 A AC-3 · 1 NO + 1 NC aux · 380 V AC coil: Elume price today ₹32,663 per pc incl. GST, 1% below the ₹32,993 MRP. The price has held steady for the last 30 days.

Price history
Elume price over time, day by day. Market comparison appears once we track this item.
14 Oct to 20 Oct
₹35,303₹34,071₹32,840₹31,608₹30,377₹32,993₹32,663
14 Oct15 Oct16 Oct17 Oct18 Oct19 Oct20 Oct
Elume today
₹32,663
MRP
₹32,993
Lowest in view · 17 Oct
₹32,663
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
3–7 working days to any site in India
📦
Wholesale built in
−5% auto-applies at 15+ units - ₹31,030/pc on this product

TeSys D contactor, 3 poles (3NO), for motor control applications up to 65A/440V AC-3/3e (30kW@400V). It provides a 380V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), power connection by EverLink BTR screw connectors, control connection by screw clamp terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (55mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).

As published by Schneider. Verify critical parameters against the datasheet before specifying.
Schneider Schneider TeSys LC1D Power Contactor · 3P · 80 A AC-3 · 1 NO + 1 NC aux · 380 V AC coil · LC1D65AQ7
Poles3P
Rated current80 A
Ingress protectionIP20 front face
Reference standardEN 60947-4-1
coil voltage380 V AC 50/60 Hz
Net weight0.86 kg
BrandSchneider
Brand SKULC1D65AQ7
ELINEFM2G9CJHH
Sold asPer pc
RangeTeSys · TeSys Deca
Motor power hp40 hp at 460/480 V AC 50/60 Hz for 3 phases motors · 5 hp at 115 V AC 50/60 Hz for 1 phase motors · 10 hp at 230/240 V AC 50/60 Hz for 1 phase motors · 20 hp at 200/208 V AC 50/60 Hz for 3 phases motors · 20 hp at 230/240 V AC 50/60 Hz for 3 phases motors · 50 hp at 575/600 V AC 50/60 Hz for 3 phases motors
Motor power kW18.5 kW at 220/230 V AC 50/60 Hz (AC-3) · 30 kW at 380/400 V AC 50/60 Hz (AC-3) · 37 kW at 500 V AC 50/60 Hz (AC-3) · 37 kW at 660/690 V AC 50/60 Hz (AC-3) · 18.5 kW at 220/230 V AC 50/60 Hz (AC-3e) · 30 kW at 380/400 V AC 50/60 Hz (AC-3e) · 37 kW at 500 V AC 50/60 Hz (AC-3e) · 37 kW at 660/690 V AC 50/60 Hz (AC-3e) · 11 kW at 400 V AC 50/60 Hz (AC-4)
Operating time4...19 ms opening · 12...26 ms closing
Coil technologyWithout built-in suppressor module
Heat dissipation4…5 W at 50/60 Hz
Pollution degree3
Protective coverWith
Range of productTeSys Deca Advanced
Average impedance1.5 mOhm - Ith 80 A 50 Hz for power circuit
Device short nameLC1D
Poles description3P
Tightening torqueControl circuit: 1.7 N.m - on EverLink BTR screw connectors - with screwdriver flat Ø 6 mm · Control circuit: 1.7 N.m - on EverLink BTR screw connectors - with screwdriver Philips No 2 · Power circuit: 8 N.m - on EverLink BTR screw connectors - cable 25…35 mm² hexagonal screw head 4 mm · Power circuit: 5 N.m - on EverLink BTR screw connectors - cable 1…25 mm² hexagonal screw head 4 mm · Control ci
Compatibility codeLC1D
Inrush power in VA140 VA 60 Hz cos phi 0.75 (at 20 °C) · 160 VA 50 Hz cos phi 0.75 (at 20 °C)
Control circuit typeAC at 50/60 Hz
Overvoltage categoryIII
Utilisation categoryAC-3 · AC-3e · AC-1 · AC-4
Contactor applicationMotor control · Resistive load
Electrical durability1.4 Mcycles 80 A AC-1 at Ue <= 440 V · 1.45 Mcycles 65 A AC-3 at Ue <= 440 V · 1.45 Mcycles 65 A AC-3e at Ue <= 440 V
Insulation resistance> 10 MOhm for signalling circuit
Mechanical durability6 Mcycles
Associated fuse rating10 A gG for signalling circuit conforming to IEC 60947-5-1 · 125 A gG at <= 690 V coordination type 1 for power circuit · 125 A gG at <= 690 V coordination type 2 for power circuit
Maximum operating rate3600 cyc/h at 60 °C
Auxiliary contacts typetype mechanically linked 1 NO + 1 NC conforming to IEC 60947-5-1 · type mirror contact 1 NC conforming to IEC 60947-4-1
Connections - terminalsControl circuit: screw clamp terminals 2 1…2.5 mm² - cable stiffness: flexible with cable end · Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible without cable end · Control circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: flexible without cable end · Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible with cable end · Control circuit:
Rated breaking capacity1000 A at 440 V for power circuit conforming to IEC 60947
Pole contact composition3 NO
Safety reliability levelB10d = 1369863 cycles contactor with nominal load conforming to EN/ISO 13849-1 · B10d = 20000000 cycles contactor with mechanical load conforming to EN/ISO 13849-1
Minimum switching current5 mA for signalling circuit
Minimum switching voltage17 V for signalling circuit
Product or component typeContactor
Irms rated making capacity140 A AC for signalling circuit conforming to IEC 60947-5-1 · 250 A DC for signalling circuit conforming to IEC 60947-5-1 · 1000 A at 440 V for power circuit conforming to IEC 60947
Power dissipation per pole9.6 W AC-1 · 6.3 W AC-3 · 6.3 W AC-3e
Signalling circuit frequency25...400 Hz
[Uc] control circuit voltage380 V AC 50/60 Hz
Auxiliary contact composition1 NO + 1 NC
[Ui] rated insulation voltagePower circuit: 600 V CSA certified · Power circuit: 600 V UL certified · Signalling circuit: 690 V conforming to IEC 60947-1 · Signalling circuit: 600 V CSA certified · Signalling circuit: 600 V UL certified · Power circuit: 690 V conforming to IEC 60947-4-1
Control circuit voltage limits0.3...0.6 Uc (-40…70 °C):drop-out AC 50/60 Hz · 0.8...1.1 Uc (-40…60 °C):operational AC 50 Hz · 0.85...1.1 Uc (-40…60 °C):operational AC 60 Hz · 1...1.1 Uc (60…70 °C):operational AC 50/60 Hz
[Ie] rated operational current80 A (at <60 °C) at <= 440 V AC AC-1 for power circuit · 65 A (at <60 °C) at <= 440 V AC AC-3 for power circuit · 65 A (at <60 °C) at <= 440 V AC AC-3e for power circuit
[Ue] rated operational voltagePower circuit: <= 690 V AC 25...400 Hz · Power circuit: <= 300 V DC
Hold-in power consumption in VA13 VA 60 Hz cos phi 0.3 (at 20 °C) · 15 VA 50 Hz cos phi 0.3 (at 20 °C)
[Uimp] rated impulse withstand voltage6 kV conforming to IEC 60947
[Icw] rated short-time withstand current640 A 40 °C - 10 s for power circuit · 900 A 40 °C - 1 s for power circuit · 110 A 40 °C - 10 min for power circuit · 260 A 40 °C - 1 min for power circuit · 100 A - 1 s for signalling circuit · 120 A - 500 ms for signalling circuit · 140 A - 100 ms for signalling circuit
[Ith] conventional free air thermal current10 A (at 60 °C) for signalling circuit · 80 A (at 60 °C) for power circuit
Ratings as published by Schneider (se.com). Verify critical parameters against the datasheet before specifying.
