Schneider IC Astro Programmable Astronomic Twilight Switch · CCT15225CCT15225↓ 1% off MRP1 / 2
BrandSchneider
CategorySwitchgear
SpecificationActi 9 IC Astro 1C SMART programmable twilight switch
Brand SKUCCT15225
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 3–7 working days
Schneider· In stock
Visit the Schneider store

Schneider IC Astro Programmable Astronomic Twilight Switch · CCT15225

NEW added this week
₹32,857/pcincl. GST-1%
₹27,845 + 18% GST · MRP ₹33,189
Add to cart
Buy now
  • Secured by Razorpay · UPI, cards, net banking, wallets
  • GST invoice with every order
  • Tracked delivery, 3 to 7 working days
✓ Full brand warranty on every order
✓Lowest price guarantee · found it cheaper? We match it.
💳 30 Day credit facility available launching soon - join waitlist.
₹32,857 /pc incl. GST
Delivery ₹1,000, ships insured

Schneider IC Astro Programmable Astronomic Twilight Switch · CCT15225: Elume price today ₹32,857 per pc incl. GST, 1% below the ₹33,189 MRP. The price has held steady for the last 30 days.

Price history
Elume price over time, day by day. Market comparison appears once we track this item.
13 Oct to 19 Oct
₹35,512₹34,273₹33,035₹31,796₹30,557₹33,189₹32,857
13 Oct14 Oct15 Oct16 Oct17 Oct18 Oct19 Oct
Elume today
₹32,857
MRP
₹33,189
Lowest in view · 17 Oct
₹32,857
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
3–7 working days to any site in India
📦
Wholesale built in
−5% auto-applies at 15+ units - ₹31,214/pc on this product

IC Astro SMART astronomic programmable twilight switch. Width of 45mm (5 modules of 9mm). To start and stop an electric load according to sunrise and sunset times. No need to use a brightness sensor as sunrise and sunset times are calculated automatically according to geographical location. Integrated time switch with swiching cycle is 7 days (weekly). 84 switching operations. Savings on mains cut off with battery reserve: 10 years. Manual and remote overrides are possible. 1 channel output. Programming could be done also with memory key and PC software. User manual holder on product left side allows to reach document easily.

As published by Schneider. Verify critical parameters against the datasheet before specifying.
Schneider Schneider IC Astro Programmable Astronomic Twilight Switch · CCT15225 · CCT15225
Ingress protectionIP20
Reference standardEN 60730-2-7:2010
Net weight0.115 kg
Device typeMiniature circuit breaker (MCB)
BrandSchneider
Brand SKUCCT15225
ELINE7776KR9PC
Sold asPer pc
Depth66.7 mm
Width45 mm
Height92.6 mm
MarkingCE
Accuracy+/- 0.25 s/day 25 °C
Load typeIncandescent lamp 2600 W · Halogen lamp 2600 W · Non-corrected fluorescent tube 2300 VA · Serial-compensated fluorescent tube 2300 VA · Parallel compensated fluorescent lamp 730 VA 80 µF · Compact fluorescent lamp 170 W · LED lamp = 2 W 200 W
StandardsEN 60730-2-7:2010
Backup time10 years
Output typeDry contact
Control typeBy calculation of sunrise/sunset times
Display typeBacklit LCD
Product nameActi9 IC
User languageEnglish · French · Danish · Dutch · Turkish · Norwegian · Spanish · Swedish · Romanian · Hungarian · Russian · Polish · Portuguese · Slovene · Bulgarian · German · Croatian · Italian
Operating modeEvening on, morning off · Evening off, morning on inactive · Only timer switch is active
Type of settingWeekly programming
Mounting supportTH35 DIN rail conforming to EN 60715
Device short nameIC Astro
Relative humidity90 %, non-condensing
Device applicationBuilding
Function availableExternal input for override · Code lock function · Holiday schedules · Automatic winter/summer time changeover · On/off permanent switching · Sunrise/sunset time offset +/- 120 min · Position setting · Switch preselection
Number of channels1
control button type4 push-buttons
Overvoltage categoryClass 3
Information displayedTime · Operating time counter (per channel) · Switching behaviour · Day
Connections - terminals2 x 0.5…2.5 mm² screw terminals solid or flexible · 1 x 2.5 mm² screw terminals solid or flexible with sleeve
IP degree of protectionIP20
Maximum switching current10 A - 250 V AC pf = 0.6 · 16 A - 250 V AC pf = 1
Minimum switching current10 mA 230 V AC · 100 mA 24 V AC/DC
Product or component typeProgrammable astronomic twilight switch
Electrical insulation classClass II
Maximum number of switchings84
Contacts type and compositionC/O
Maximum power consumption in W0.5 W standby
[Ue] rated operational voltage230 V AC +10 % -15 % at 50/60 Hz
Ambient air temperature for operation-30…55 °C
ambient air temp for storage/transportation-30…70 °C
Ratings as published by Schneider (se.com). Verify critical parameters against the datasheet before specifying.
