BrandHavells
SKUMHPAVE0X50
Sold asPer pc
Power0.37 kW (0.5 HP)
ShaftStainless Steel (SS-410)
ImpellerForged brass
Warranty1 Year
Pipe Size25 mm x 25 mm
Motor BodyHigh-quality die casted aluminium
Motor Speed2850 Revolution per minute
Pump CasingGraded Cast Iron
ApplicationsApartments, bungalows, farm-houses, building construction, gardening, fountains, overhead storage tanks, pressure booster systems, hotels, hospitals, industrial water circulation
Gross Weight11.63 kg
Motor StatorLow watt loss stamping
Net Contents1 N Pump Set, 1 N Instruction Manual, 1 N Warranty Card, 1 N Suction Strainer
Net Quantity1 N
Suitable ForSingle Phase supply
Winding TypeCopper winding
Product rangeMonoblock Pump
Manufactured ByHavells India Ltd.
Rated Frequency50 Hz
Country Of OriginIndia
Power Supply CableYes
Packaging Dimensions330.2 mm x 203.2 mm x 304.8 mm
Direction of Rotatingclockwise when viewed from fan cover side
Low Power ConsumptionYes
Motor Insulation ClassClass F
Voltage Operating Range180 V to 240 V
Dynamically Balanced RotorYes
Operating Water Temperatureup to 50 °C
High Quality Mechanical SealYes
High Suction With Self Primingup to 8 m
In Built Thermal Overload ProtectorYes
Pump Motor Coupling as Per Nema StandardYes
