Schneider Harmony RPZ Socket · RPZF4RPZF4↓ 1% off MRP1 / 9
BrandSchneider
CategoryIndustrial Control
SpecificationSocket, mixed contact, 16 A, relay type RPM4, screw clamp terminals, 250 V AC
Brand SKURPZF4
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 3–7 working days
Schneider· In stock
Visit the Schneider store

Schneider Harmony RPZ Socket · RPZF4

NEW added this week
₹1,600/pcincl. GST-1%
₹1,356 + 18% GST · MRP ₹1,617
Add to cart
Buy now
  • Secured by Razorpay · UPI, cards, net banking, wallets
  • GST invoice with every order
  • Tracked delivery, 3 to 7 working days
✓ Full brand warranty on every order
✓Lowest price guarantee · found it cheaper? We match it.
💳 30 Day credit facility available launching soon - join waitlist.
₹1,600 /pc incl. GST
Free delivery over ₹4,000

Schneider Harmony RPZ Socket · RPZF4: Elume price today ₹1,600 per pc incl. GST, 1% below the ₹1,617 MRP. The price has held steady for the last 30 days.

Price history
Elume price over time, day by day. Market comparison appears once we track this item.
13 Oct to 19 Oct
₹1,730₹1,670₹1,609₹1,549₹1,488₹1,617₹1,600
13 Oct14 Oct15 Oct16 Oct17 Oct18 Oct19 Oct
Elume today
₹1,600
MRP
₹1,617
Lowest in view · 17 Oct
₹1,600
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
3–7 working days to any site in India
📦
Wholesale built in
−5% auto-applies at 15+ units - ₹1,520/pc on this product

"This Harmony RPM plug-in socket has a rated voltage of 250V AC with an output rating of 16A." "This plug-in relay socket is compatible with interface plug-in relay RXM range." "It has a large choice of number of contacts for high rated current use with space-saving design which allows for a flexible and easy installation on DIN rail." "It helps to reduce the size of enclosures and increase machine reliability, you can mount nearly everywhere." "It is compatible with plug in control relay." "It enables easy installation and connect to relay from its socket." "Workability for hard-wired logic automated systems to complement the functions of industrial programmable logic controllers (PLCs)."

As published by Schneider. Verify critical parameters against the datasheet before specifying.
Schneider Schneider Harmony RPZ Socket · RPZF4 · RPZF4
Ingress protectionIP20
Reference standardIEC 61984
Net weight0.094 kg
BrandSchneider
Brand SKURPZF4
ELINEH3D23KRJM
Sold asPer pc
Width50 mm
MarkingCE
StandardsIEC 61984
Fixing modeBy screw (panel) · Clip-on (35 mm symmetrical DIN rail)
Shape of pinFlat
Pollution degree3
Range of productHarmony Electromechanical Relays
Device short nameRPZ
Tightening torque< 1 N.m for M3.5 screw(s)
Dielectric strength2500 V
Overvoltage categoryIII
Product compatibilityPlug-in relay RPM with 4 C/O contact
Product certificationsUL · CSA
Connections - terminals- screw clamp terminals, flexible cable with cable end 1 x 0.5...1 x 2.5 mm² / 20 AWG...14 AWG · - screw clamp terminals, solid cable without cable end 1 x 0.5...1 x 1.5 mm² / 20 AWG...16 AWG · - screw clamp terminals, flexible cable with cable end 2 x 0.5...2 x 2.5 mm² / 20 AWG...14 AWG · - screw clamp terminals, solid cable without cable end 2 x 0.5...2 x 1.5 mm² / 20 AWG...16 AWG
IP degree of protectionIP20 conforming to IEC 60529
Product or component typeSocket
Contact terminal arrangementMixed
Contacts type and composition4 C/O
Sale per indivisible quantity10
[Ue] rated operational voltage< 250 V
Ambient air temperature for storage-40…85 °C
Ambient air temperature for operation-40…55 °C
[Uimp] rated impulse withstand voltage4 kV
[Ith] conventional free air thermal current16 A
Ratings as published by Schneider (se.com). Verify critical parameters against the datasheet before specifying.
