Schneider TeSys CA2K Control Relay · 2 NO + 2 NC · 10 A · 230 V AC 50/60 Hz coilCA2KN22P7↓ 1% off MRP1 / 3
BrandSchneider
CategoryIndustrial Control
Brand SKUCA2KN22P7
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 3–7 working days
Schneider· In stock
Visit the Schneider store

Schneider TeSys CA2K Control Relay · 2 NO + 2 NC · 10 A · 230 V AC 50/60 Hz coil

Coil: 230 V AC 50/60 Hz coil
NEW added this week
₹3,610/pcincl. GST-1%
₹3,059 + 18% GST · MRP ₹3,646
Add to cart
Buy now
  • Secured by Razorpay · UPI, cards, net banking, wallets
  • GST invoice with every order
  • Tracked delivery, 3 to 7 working days
✓ Full brand warranty on every order
✓Lowest price guarantee · found it cheaper? We match it.
💳 30 Day credit facility available launching soon - join waitlist.
₹3,610 /pc incl. GST
Free delivery over ₹4,000

Schneider TeSys CA2K Control Relay · 2 NO + 2 NC · 10 A · 230 V AC 50/60 Hz coil: Elume price today ₹3,610 per pc incl. GST, 1% below the ₹3,646 MRP. The price has held steady for the last 30 days.

Price history
Elume price over time, day by day. Market comparison appears once we track this item.
13 Oct to 19 Oct
₹3,901₹3,765₹3,629₹3,493₹3,357₹3,646₹3,610
13 Oct14 Oct15 Oct16 Oct17 Oct18 Oct19 Oct
Elume today
₹3,610
MRP
₹3,646
Lowest in view · 17 Oct
₹3,610
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
3–7 working days to any site in India
📦
Wholesale built in
−5% auto-applies at 15+ units - ₹3,430/pc on this product

TeSys K control relay, 4 contacts (2NO + 2NC), 10A/690V, for control of electromagnetic loads AC-15/DC-13. It provides a 230V 50/60Hz AC control circuit, connection by screw clamp terminals. For high operating rates until 180 cycles/min and ambient temperature -25/+50°C, it procures high reliability and durability. Compact (45mm width), for clipping on 35mm DIN rail or fixing by screw. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium product (RoHS/REACh).

As published by Schneider. Verify critical parameters against the datasheet before specifying.
Schneider Schneider TeSys CA2K Control Relay · 2 NO + 2 NC · 10 A · 230 V AC 50/60 Hz coil · CA2KN22P7
Ingress protectionIP2X
Reference standardEN/IEC 60947-5-1
coil voltage230 V AC 50/60 Hz
Net weight0.18 kg
BrandSchneider
Brand SKUCA2KN22P7
ELINE97MMJCCHG
Sold asPer pc
Depth57 mm
RangeTeSys
Width45 mm
Height58 mm
StandardsEN/IEC 60947-5-1 · GB/T 14048.5 · UL 60947-5-1 · CSA C22.2 No 60947-5-1 · JIS C8201-5-1
Product nameTeSys CAK
Operating time10...20 ms coil de-energisation and NO opening · 10...20 ms coil energisation and NO closing · 15...25 ms coil de-energisation and NC closing · 5...15 ms coil energisation and NC opening
Flame retardanceV1 conforming to UL 94 · Requirement 2 conforming to NF F 16-101 · Requirement 2 conforming to NF F 16-102
Heat dissipation1.3 W
Mounting supportRail · Plate
Device short nameCA2K
Tightening torque1.3 N.m - on screw clamp terminals - with screwdriver flat Ø 6 mm · 1.3 N.m - on screw clamp terminals - with screwdriver Philips No 26 mm · 1.3 N.m - on screw clamp terminals - with screwdriver pozidriv No 2
Inrush power in VA30 VA (at 20 °C)
Operating altitude2000 m without derating
Control circuit typeAC at 50/60 Hz
Non overlap distance0.5 mm
Protective treatmentTC conforming to IEC 60068
Utilisation categoryAC-15 · DC-13
Contactor applicationControl circuit
Insulation resistance> 10 MOhm
Mechanical durability10 Mcycles
Mechanical robustnessVibrations contactor open: 2 Gn, 5...300 Hz conforming to IEC 60068-2-6 · Vibrations contactor closed: 4 Gn, 5...300 Hz conforming to IEC 60068-2-6 · Shocks contactor open: 10 Gn for 11 ms conforming to IEC 60068-2-27 · Shocks contactor closed: 15 Gn for 11 ms conforming to IEC 60068-2-27
Associated fuse rating10 A gG conforming to IEC 60947 · 10 A gG conforming to VDE 0660
Maximum operating rate10000 cyc/h
Product certificationsCB Scheme · CCC · UL · CSA · EAC · CE · UKCA
Connections - terminalsScrew clamp terminals 1 cable(s) 1.5…4 mm²solid · Screw clamp terminals 2 cable(s) 1.5…4 mm²solid · Screw clamp terminals 1 cable(s) 0.75…4 mm²flexible with cable end · Screw clamp terminals 2 cable(s) 0.75…4 mm²flexible without cable end · Screw clamp terminals 1 cable(s) 0.34…1.5 mm²flexible with cable end · Screw clamp terminals 2 cable(s) 0.34…1.5 mm²flexible without cable end
IP degree of protectionIP2X
Immunity to microbreaks2 ms
Pole contact composition2 NO + 2 NC
Minimum switching current5 mA
Minimum switching voltage17 V
Product or component typeControl relay
Irms rated making capacity110 A conforming to IEC 60947
[Uc] control circuit voltage230 V AC 50/60 Hz
[Ui] rated insulation voltage690 V conforming to IEC 60947 · 750 V conforming to VDE 0110 group C · 690 V conforming to BS 5424 · 600 V conforming to CSA C22.2 No 14
Control circuit voltage limitsDrop-out: 0.2...0.75 Uc (at <50 °C) · Operational: 0.8...1.15 Uc (at <50 °C)
[Ue] rated operational voltage<= 690 V <= 400 Hz
Hold-in power consumption in VA4.5 VA (at 20 °C)
Ambient air temperature for storage-50…80 °C
Ambient air temperature for operation-25…50 °C
[Ith] conventional free air thermal current10 A (at 50 °C)
Ratings as published by Schneider (se.com). Verify critical parameters against the datasheet before specifying.
