Schneider Harmony Control Relay · RM10TG00RM10TG00↓ 1% off MRP
BrandSchneider
CategoryIndustrial Control
SpecificationModular measurement and relay, Harmony relay, for 3-phase supply, without time delay, 183...528V AC, 1 C/O
Brand SKURM10TG00
AvailabilityIn stock · ships in 24h
DeliveryPan-India · 3–7 working days
Schneider· In stock
Visit the Schneider store

Schneider Harmony Control Relay · RM10TG00

NEW added this week
₹4,781/pcincl. GST-1%
₹4,052 + 18% GST · MRP ₹4,830
Add to cart
Buy now
  • Secured by Razorpay · UPI, cards, net banking, wallets
  • GST invoice with every order
  • Tracked delivery, 3 to 7 working days
✓ Full brand warranty on every order
✓Lowest price guarantee · found it cheaper? We match it.
💳 30 Day credit facility available launching soon - join waitlist.
₹4,781 /pc incl. GST
Free pan-India delivery

Schneider Harmony Control Relay · RM10TG00: Elume price today ₹4,781 per pc incl. GST, 1% below the ₹4,830 MRP. The price has held steady for the last 30 days.

Price history
Elume price over time, day by day. Market comparison appears once we track this item.
13 Oct to 19 Oct
₹5,168₹4,988₹4,807₹4,627₹4,446₹4,830₹4,781
13 Oct14 Oct15 Oct16 Oct17 Oct18 Oct19 Oct
Elume today
₹4,781
MRP
₹4,830
Lowest in view · 17 Oct
₹4,781
🏷️
100% genuine
Brand-authorised stock with full manufacturer warranty
🧾
GST invoice
Tax invoice on every order · GST billing with tax split
🚚
Pan-India delivery
3–7 working days to any site in India
📦
Wholesale built in
−5% auto-applies at 15+ units - ₹4,542/pc on this product

Schneider Harmony Control Relay · RM10TG00 from Schneider Electric.

As published by Schneider. Verify critical parameters against the datasheet before specifying.
Schneider Schneider Harmony Control Relay · RM10TG00 · RM10TG00
Ingress protectionIP20 (terminals)· IP30 (casing)
Reference standardEN/IEC 60255-1
Net weight0.085 kg
BrandSchneider
Brand SKURM10TG00
ELINE7PDR3PKG7
Sold asPer pc
Depth72 mm
Width17.5 mm
Height90 mm
MarkingCE
StandardsEN/IEC 60255-1
Directives89/336/EEC - electromagnetic compatibility · 73/23/EEC - low voltage directive
Relay nameRM10TG
Relay typeControl relay
Response time<= 130 ms (in the event of a fault)
Output contacts1 C/O
Time delay typeWithout
Housing materialPolycarbonate
Local signallingLED (yellow) for relay ON
Mounting support35 mm symmetrical DIN rail conforming to EN/IEC 60715
Pollution degree3 conforming to IEC 60664-1
Range of productHarmony Relay
Reliability dataB10d = 850000 · MTTFd = 924.6 years
Supply frequency50/60 Hz +/- 10 %
Relative humidity95 % at 55 °C conforming to IEC 60068-2-30
Tightening torque0.6…1 N.m conforming to IEC 60947-1
Operating positionAny position without derating
Overvoltage categoryIII conforming to IEC 60664-1
Electrical durability100000 cycles
Insulation resistance> 500 MOhm at 500 V DC conforming to IEC 60255-5
Mechanical durability30000000 cycles
Supply voltage limits183…528 V AC
Product certificationsC-Tick · GOST · UL · CSA · GL
nominal output current5 A
Connections - terminalsScrew terminals, 1 x 0.5...1 x 4 mm² (20 AWG...11 AWG) solid without cable end · Screw terminals, 2 x 0.5...2 x 2.5 mm² (20 AWG...14 AWG) solid without cable end · Screw terminals, 1 x 0.2...1 x 2.5 mm² (24 AWG...12 AWG) flexible with cable end · Screw terminals, 2 x 0.2...2 x 1.5 mm² (24 AWG...16 AWG) flexible with cable end
Dielectric test voltage2 kV, 1 min AC 50 Hz
IP degree of protectionIP20 (terminals) conforming to IEC 60529 · IP30 (casing) conforming to IEC 60529
Power consumption in VA0…22 VA at 400 V AC 50 Hz
Switching capacity in VA1250 VA
Control circuit frequency50...60 Hz +/- 10 %
Maximum switching voltage250 V AC
Minimum switching current10 mA at 5 V DC
Product or component typeModular measurement and control relays
Relay monitored parametersPhase sequence · Phase failure detection
Voltage detection threshold< 100 V AC
Product specific applicationFor 3-phase supply
Electromagnetic compatibilityEmission standard for industrial environments conforming to EN/IEC 61000-6-4 · Emission standard for residential, commercial and light-industrial environments conforming to EN/IEC 61000-6-3 · Immunity for industrial environments conforming to EN/IEC 61000-6-2
[Ui] rated insulation voltage400 V conforming to IEC 60664-1
Control circuit voltage limits- 12 % + 10 % Un
Ambient air temperature for storage-40…70 °C
Ambient air temperature for operation-20…50 °C
Ratings as published by Schneider (se.com). Verify critical parameters against the datasheet before specifying.
